HP2503C-2×11Y/1001 2.50mm 22-Position Plug Housing Connector Overview
HP2503C-2×11Y/1001 is a plug housing connector in ZUCH’s 2.50mm XAD Series. Key selection details include spacing: 2.50mm; digits: 22; material: PA66.
For connector selection, review the cavity arrangement, mating part and contact specification together.
2.50mm 22-Position Plug Housing Connector Mating and Contact Selection
-
Mating interface
Confirm the mating housing, contact cavity and keying against the exact series drawing. Equal pitch alone does not establish interchangeability.
-
Contact and assembly
Confirm the approved contact part number, conductor range and retention features. A housing is not a complete terminated connector assembly.
-
Electrical conditions
Review the housing voltage field separately from the contact current requirement. Confirm the assembled system rating and installation environment.
Model and color identification
The catalog color for HP2503C-2×11Y/1001 is white. Confirm the complete manufacturing code when selecting a color or version; matching color alone does not identify a mating component.
ZUCH Engineering Support for Plug Housing Connector Projects
ZUCH describes its R&D, laboratory and digital-manufacturing capabilities on its company pages. For this product, request the relevant drawing review and quality documents from the sales or engineering team.
Plug Housing Connector Selection Guide and Sample Requests
PA66 Plug Housing Connector Selection and Assembly FAQ
What is the HP2503C-2×11Y/1001 connector housing, and are contacts included?
ZUCH lists HP2503C-2×11Y/1001 as a plug housing in its 2.50mm XAD Series. A housing designation alone does not establish the supplied contents. Confirm whether the quotation includes contacts, the mating component and any assembly accessories, or the housing only.
How do I check the connector pitch and position layout of HP2503C-2×11Y/1001?
The published spacing is 2.50mm, with 22 positions in 2 rows. Check center-to-center contact spacing against the drawing, rather than measuring the outside of the housing. Verify row-to-row spacing separately; it is not established by the contact pitch. Confirm cavity numbering and orientation before selecting the counterpart.
Is HP2503C-2×11Y/1001 a male or female connector housing?
The catalog identifies HP2503C-2×11Y/1001 as a plug housing; this does not by itself specify whether its approved contacts are pins or sockets. Housing form and contact gender are separate selection details. Confirm the contact interface and mating-part drawing with ZUCH before ordering.
Can HP2503C-2×11Y/1001 mate with a similar housing of the same color?
The listed housing color is white. Color and a similar appearance do not prove mating compatibility. Compare the cavity pattern, contact interface, polarization, keying and latch geometry on the two drawings, then ask ZUCH to confirm the approved mating part for HP2503C-2×11Y/1001.
What should I confirm about the PA66 housing material used in HP2503C-2×11Y/1001?
The material published for HP2503C-2×11Y/1001 is PA66. The exact resin grade, reinforcement and flammability classification are not given in this record. Confirm those requirements and any relevant material documentation with ZUCH; the PA66 label alone does not establish them.
What IP rating does HP2503C-2×11Y/1001 have, and can it be used outdoors?
No IP rating or outdoor-use approval is published in the target record for HP2503C-2×11Y/1001. Its material and usage-environment field do not establish a sealed connection. Confirm the tested protection rating, mating condition and any required seals for the complete assembly before specifying wet, dusty or outdoor service.
Does the voltage rating of HP2503C-2×11Y/1001 determine its current capacity?
The published rated voltage is 250V; this is not a current rating. The target record does not state a current limit. Ask ZUCH to confirm the allowable current with the approved contacts, wire size, circuit loading and ambient conditions, rather than calculating an amperage from the voltage field.
How should contacts be installed and checked in HP2503C-2×11Y/1001?
Confirm the approved terminal, wire range, crimp tooling and insertion orientation before assembly. Request the insertion and retention checks for HP2503C-2×11Y/1001, and verify that each contact is fully seated before mating. Do not force a contact or assume that a secondary lock is included.
Need help with your project?
Share the model, drawings and application requirements with the ZUCH team.
Request a Quote for HP2503C-2×11Y/1001 Plug Housing Connector
For HP2503C-2×11Y/1001, send the intended application, quantity, mating or assembly drawing and conductor requirements. Confirm sample availability, minimum order, lead time and packaging with ZUCH.
